| برند محصول | HighPoint Technologies, Inc. |
|---|---|
| سری محصول | RocketRAID |
| مدل محصول | RR4522SGL |
| فرم فاکتور (قالب) | Low Profile |
| نوع | SATA/SAS |
| اتصالات داخلی | 2x SFF-8088 mini-SAS |
| نوع رابط | PCI Express 2.0 x8 |
| نرخ انتقال | Up to 6Gb/s |
| RAID | RAID 0/1/5/6/10/50 JBOD |
| سیستم عامل پشتیبانی شده | Driver embedded into FreeBSD 9.0 and later, Driver embedded into OSx 10.9 and later, FreeBSD 8.3 and later, Linux Driver embedded into Kernel 3.9.4 and later, Linux: RedHat Enterprise, Open SuSE, Fedora Core, Debian, Ubuntu, Mac OSx 10.6 and later, Window Server 2008 and Window 7 and later |
| ویژگی ها | 4Kn Drive Compatible, Advanced RAID Features:, Auto Rebuild on spare drive, Backwards Compatibility: backward compatible with single disks/RAID array created with HighPoint RAID HBA, Bootable RAID Array support, Data Transfer Rate: Up to 6Gb/s per channel, Device Ports: Dual External Mini-SAS ports (SFF-8088), Devices Interface: Mini-SAS, SATA (Port Multiplier) (cables sold separately), Dual-Storage Modes: LTO Tape and RAID Arrays, DV Mode Technology, Enhanced data protection with Write Journaling feature, Host Interface: PCIe 2.0 x8, Hot-Plug and Hot-Swap support, Larger than 3 TB drive support, Monitoring and Management Support: SMTP, SGPIO, SES2, LED Status, Event Log, Native Command Queuing, No. of Disk(s): Directly supports up to 8 SAS/SATA HDD/SSD, up to 20 via SATA Port Multiplier, up to 128 via SAS Expander, NVRAM keeps tracks I/O transaction logs, O.S. Support: Mac OSx 10.8.6 or greater and Windows 7 and 8., Optional Battery Backup: HPTBBU-05, RAID 0, 1, 5, 6, 10, 50, JBOD, RAID Initialization Types - Background, Foreground and Quick, RAID Levels: Integrated Hardware RAID 0, 1, 5, 6, 10, 50 & JBOD, RAID Suite: User friendly Browser-based Management Interface, Redundant RAID Configurations, ROHS Compliant: Yes, S.M.A.R.T. Support, Spin Down Idle Disk, Staggered Drive Spin Up, Supports OCE / ORLM, System Support: Mac and PC Systems with PCIe support, Write Back or Write Through Cache support |
| ابعاد | 2.67"x6.58" |
| محتویات بسته بندی | 1x Low Profile Bracket, 1x Quick Installation Guide, 1x RocketRAID 4522 Controller card |
