Supermicro
X9SRA
ATX
Intel Xeon Processor E5-1600 v3
LGA2011
Intel C602
8 x 240pin
DDR3 1866 / 1600 / 1333 / 1066 MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
Up to 256GB DDR3 ECC RDIMM, Up to 512GB DDR3 ECC LRDIMM, Up to 64GB DDR3 ECC / non-ECC UDIMM
بلی
2 x PCI-E 3.0 x16 slots
1 x PCI-E 3.0 x4 (in x8 slot), 1 x PCI-E 2.0 x4 (in x8) slot
1 x PCI-32 slot
4 x SATA 3.0Gb/s + 2 x SATA 6.0Gb/s
RAID 0, 1, 10 support (Linux), RAID 0/1/5/10 support (Windows)
Realtek ALC889
Line-in / Line-out / Microphone Ports
7.1 High Definition Audio with S/PDIF header
Intel 82579LM
10/100/1000Mbps
Dual 10/100/1000Mbps
Intel 82574L
2 x USB 3.0 + 8 x USB 2.0
1 x PS/2 keyboard/mouse port
Expansion slots: 2 x PCI-E 3.0 x8 (in x16), 4 x PCI-E 3.0 x8, 1 x PCI-E 3.0 x4 (in x8), 2 x SATA3 (6Gb/s), 4 x SATA (3Gb/s), & 4 x SATA2 (3Gb/s) ports via SCU, 4 x USB 3.0 (5 Gbps) ports (2 x rear, 2 x via header) & 14 x USB 2.0 ports (8 x rear, 6 x via header), DOM power connector support, Dual Gigabit Ethernet LAN Ports, Intel C602 chipset, Single socket R (LGA 2011) supports Intel Xeon processor E5-2600/1600 and E5-2600/1600 v2 family ,2nd and 3rd Gen. Core i7 series processors (Ci7 CPU only works w/Non-ECC UDIMM), Up to 512GB ECC DDR3, up to 1866MHz; 8x DIMM sockets
12.0" x 9.6"
