برند محصول |
GIGABYTE
|
مدل محصول |
S472-Z30
|
نوع |
Rackmount
|
فرم فاکتور (قالب) |
4U
|
نوع پردازنده |
AMD EPYC 7002 series, AMD EPYC 7003 Series
|
سوکت پردازنده |
SP3
|
بیشترین تعداد پردازنده |
1
|
at_installed-cpu |
بدون پردازنده
|
at_memory-type-supported |
DDR4 3200
|
اسلات های حافظه |
16x 288Pin
|
میزان حافظه نصب شده |
بدون حافظه رم
|
کانال های پشتبانی شده |
8 کانال
|
at_installed-hdd |
بدون حافظه ذخیره سازی
|
M2 |
2x M.2
|
at_hot-swap-bays |
– 4x 2.5" SATA/SAS/NVMe hybrid hot-swap SSD bays, – 8x 2.5" NVMe hot-swap SSD bays, 12x 2.5" SATA/SAS hot-swap SSD bays, 24x 2.5" SATA/SAS/NVMe hot-swap SSD bays (front side), 24x 3.5" SATA/SAS hot-swap HDD/ SSD bays (right side & left side), 2x 2.5" SATA hot-swap SSD bays (rear side)
|
at_gpu-vpu |
Aspeed AST2500
|
at_vga |
1
|
LAN اول |
Intel I350-AM2
|
حداکثر سرعت LAN |
10/100/1000Mbps
|
پورت RJ45 |
1x MLAN, 2x RJ45
|
at_pci-express |
1x OCP 2.0 mezzanine slot with PCIe Gen3 (x16) bandwidth (Type1, P1, P2, P3, P4), Slot1: 1x PCIe (x16) (Gen3 (x16) or (x8) bus) slot; shared with Slot2, Slot2: 1x PCIe (x8) (Gen3 x0 or (x8) bus) slot, Slot3: 1x PCIe (x16) (Gen4 (x16) bus) slot, Slot4: 1x PCIe (x16) (Gen4 (x16) bus) slot occupied by CNV3134, 4x Gen4 NVMe HBA, Slot5: 1x PCIe (x16) (Gen4 (x8) bus) slot, Slot6: 1x PCIe (x16) (Gen4 (x16) bus) slot, occupied by CNV3134, 4x Gen4 NVMe HBA
|
at_front-usb |
2x USB 3.0
|
at_rear-usb |
3x USB 3.0
|
پورت COM |
1
|
پورت های دیگر |
1x 24-pin ATX main power connector, 1x BIOS recovery jumper, 1x Buzzer, 1x Clear CMOS jumper, 1x Front panel header, 1x HDD back plane board header, 1x IPMB connector, 1x PMBus connector, 1x TPM header, 2x 8-pin ATX 12V power connectors, 2x CPU fan headers, 2x M.2 slots, 5x System fan headers, Internal I/O
|
at_max-power |
2x 1600W redundant PSUs, 80 PLUS Platinum
|
دما |
Non-operating temperature: -40°C to 60°C, Operating temperature: 10°C to 35°C
|
رطوبت |
Non-operating humidity: 20%-95% (non-condensing), Operating humidity: 8-80% (non-condensing)
|
at_system-compatibility |
Citrix Hypervisor 8.2.0 or later, Red Hat Enterprise Linux 8.3 ( x64) or later, SUSE Linux Enterprise Server 12 SP5 ( x64) or later, Ubuntu 18.04.5 LTS (x64) or later, Ubuntu 20.04 LTS (x64) or later, Ubuntu 22.04 LTS (x64) or later, VMware ESXi 6.7 Update3 P03 or later, VMware ESXi 7.0 Update1 or later, Windows Server 2016 ( X2APIC/256T not supported), Windows Server 2019, Windows Server 2022
|
ابعاد |
18.98" x 6.89" x 27.43"
|
