برند محصول |
GIGABYTE
|
مدل محصول |
H242-Z11
|
نوع |
Rackmount
|
فرم فاکتور (قالب) |
2U
|
نوع پردازنده |
AMD EPYC
|
سوکت پردازنده |
SP3
|
بیشترین تعداد پردازنده |
4
|
at_installed-cpu |
بدون پردازنده
|
at_memory-type-supported |
DDR4 3200
|
اسلات های حافظه |
8 DIMM per Node
|
میزان حافظه نصب شده |
بدون حافظه رم
|
کانال های پشتبانی شده |
8 کانال
|
at_installed-hdd |
بدون حافظه ذخیره سازی
|
M2 |
2x M.2
|
2.5 اینچ Bays |
1x 2.5" NVMe hot-swappable SSD bays
|
at_gpu-vpu |
Aspeed AST2500
|
at_vga |
1x VGA
|
LAN اول |
1x Dedicated management port, 2x 1GbE LAN ports (1x Intel I350-AM2), NCSI function supported, Per node:
|
حداکثر سرعت LAN |
10/100/1000Mbps
|
پورت RJ45 |
1x MLAN, 2x RJ45, Per node:
|
at_pci-express |
1x Low profile half-length slots with PCIe (x16) (Gen4 (x16) bus), 1x OCP 2.0 mezzanine slot with PCIe Gen3 (x16) bandwidth (Type1, P1, P2, P3, P4), Per node:
|
at_front-usb |
2x USB 3.0
|
پورت های دیگر |
1x Back plane board header, 1x BIOS recovery jumper, 1x Clear CMOS jumper, 1x Front panel header, 1x IPMB connector, 1x OCP 2.0 mezzanine slots, 1x TPM header, 1x USB 3.0 header, 2x M.2 slot, Per node:
|
at_max-power |
2x 1200W redundant PSUs, 80 PLUS Platinum
|
دما |
Non-operating temperature: -40°C to 60°C, Operating temperature: 10°C to 35°C
|
رطوبت |
Non-operating humidity: 20%-95% (non-condensing), Operating humidity: 8-80% (non-condensing)
|
at_system-compatibility |
Citrix Hypervisor 8.2.0 or later, Red Hat Enterprise Linux 8.3 ( x64) or later, SUSE Linux Enterprise Server 12 SP5 ( x64) or later, Ubuntu 18.04.5 LTS (x64) or later, Ubuntu 20.04 LTS (x64) or later, Ubuntu 22.04 LTS (x64) or later, VMware ESXi 6.7 Update3 P03 or later, VMware ESXi 7.0 Update1 or later, Windows Server 2016 ( X2APIC/256T not supported), Windows Server 2019, Windows Server 2022
|
