برند محصول | Supermicro |
---|
مدل محصول | SYS-8027R-7RFT+ |
---|
نوع | Rackmount |
---|
فرم فاکتور (قالب) | 2U |
---|
نوع پردازنده | Intel Xeon E5-2600 v4/v3 Series |
---|
سوکت پردازنده | LGA2011 |
---|
بیشترین تعداد پردازنده | 4 |
---|
at_installed-cpu | بدون پردازنده |
---|
چیپ ست North Bridge | Intel C602 |
---|
at_memory-type-supported | DDR3 1866/1600/1333/1066/800 |
---|
اسلات های حافظه | 32x 240Pin |
---|
میزان حافظه نصب شده | بدون حافظه رم |
---|
at_max-memory-supported | 1TB |
---|
at_installed-hdd | بدون حافظه ذخیره سازی |
---|
SAS | 8x SAS2 ports (6Gbps) via LSI 2208 controller |
---|
SATA RAID | SATA 2.0 3Gbps with RAID 0/1/5/10, SATA 3.0 6Gbps with RAID 0/1 |
---|
at_serial-ata | 2x SATA 600 + 4x SATA 300 |
---|
at_scsi-raid | 1, 10), 5, 6, Host RAID (0 |
---|
3.5 اینچ Bays | 6x 3.5" SAS2/SATA3 Drive Bays |
---|
at_gpu-vpu | Matrox G200eW (Nuvoton WPCM450 BMC) |
---|
at_vga | 1 |
---|
LAN اول | Intel X540 |
---|
حداکثر سرعت LAN | 10/100/1000Mbps |
---|
پورت RJ45 | 1x dedicated LAN port for IPMI, 2x RJ45 10GBase-T ports |
---|
at_pci-express | 4x PCI-E 3.0 (x16) (2 in x8) Slots |
---|
at_rear-usb | 4 |
---|
پورت COM | 1x Fast UART 16550 serial port |
---|
پشتیبانی ECC | بلی |
---|
رجیستر شده | بلی |
---|
ویژگی ها | 2x Network activity LEDs, Buttons, Fans: 3x 8cm Hot-swap Cooling fans, Front Panel, Hard drive activity LED, IPMI 2.0 with virtual media over LAN and KVM-over-LAN support, LEDs:, Nuvoton WPCM450 BMC, Power LED, Power On/Off button, SAS/SATA HDD Backplane (SAS support requires optional SAS controller), Shroud: 1x Air Shroud, Support for Intelligent Platform Management Interface v.2.0, System Cooling, System Overheat LED, System Reset button |
---|
at_max-power | Redundant 1400W High-efficiency AC power supply with Digital Switching Control & PMBus 1.2 |
---|
ابعاد | 27.9" x 17.2" x 3.5" (D x W x H) |
---|
