برند محصول | ASRock Rack |
---|
مدل محصول | 1U2LW-X470 |
---|
نوع | Rackmount |
---|
فرم فاکتور (قالب) | 1U |
---|
نوع پردازنده | AMD AM4 Socket Ryzen Series CPUs (Raven Ridge, Pinnacle Ridge), Ryzen 7nm CPUs |
---|
سوکت پردازنده | AM4 |
---|
بیشترین تعداد پردازنده | 1 |
---|
at_installed-cpu | بدون پردازنده |
---|
at_memory-type-supported | ECC/UDIMM: 3200/2933/2666/2400/2133 MHz, ECC/UDIMM: 32GB, 16GB, 8GB, Support DDR4 ECC/UDIMM, Voltage: 1.2V |
---|
اسلات های حافظه | 4x 288Pin |
---|
میزان حافظه نصب شده | بدون حافظه رم |
---|
at_max-memory-supported | 128GB |
---|
کانال های پشتبانی شده | 2 کانال |
---|
SATA RAID | RAID 0/1/10 |
---|
at_serial-ata | 6x SATA3 6.0 Gb/s (1x SATA DOM port), support RAID 0, 1, 10 |
---|
3.5 اینچ Bays | 2 |
---|
at_gpu-vpu | Aspeed AST2500 |
---|
at_vga | 1 |
---|
تعداد LAN | 2x RJ45 GLAN by Intel i210 |
---|
LAN اول | Intel I210 |
---|
at_second-lan | Intel I210 |
---|
حداکثر سرعت LAN | 2x 10/100/1000Mbps |
---|
at_pci-express | PCIe 3.0x 16, PCIe 3.0x 8, PCIE6: Gen3 (x16) link (splittable in x4/4/4/4); auto switch to (x8) link when PCIE4 is occupied., SLOT4: Gen3 (x8) link, SLOT5: Gen3 x4 link |
---|
at_front-usb | 2x USB 2.0 ports |
---|
at_rear-usb | 2x USB 3.2 Gen1 |
---|
پورت COM | 1x Serial Port |
---|
پشتیبانی ECC | بلی |
---|
ویژگی ها | – Internal: 2x 3.5" HDD or 1x 3.5" HDD & 1x 2.5" HDD, – LAN Ports with LED (ACT / LINK LED and SPEED LED), – Power Switch, – RJ45: 2+1 (IPMI), – System reset, 1U Rackmount with 315W PSU, ASPEED 2500 for BMC controller, Realtek RTL8211E for dedicated IPMI GLAN, Buttons, Chipset: AMD Promontory X470, CPU: AMD AM4 Socket Ryzen Series CPUs (Raven Ridge and Pinnacle Ridge) and Ryzen 7nm CPUs, External Drive Bay:, External: 1x Slim ODD, Front Panel, Front Side Drive Bay, I/O Ports: 2x USB 2.0 ports, Lan Port:, LEDs: Power status, HDD, Lan activity LEDs, MB tray:, Processor System:, Serial Port: 1, Socket: AM4 PGA 1331, Supports 1x PCIe 3.0 x16, Supports 2x Intel i210, Supports 4x DDR4 ECC and non-ECC UDIMM, max. 64 GB, Supports AMD AM4 Socket Ryzen Series CPUs and Ryzen 7nm CPUs, Supports internal 2x 3.5" HDD or 1x 3.5" HDD + 1x 2.5" HDD, external: 1x Slim ODD, USB 3.0: 2, VGA: 1x D-Sub |
---|
ویژگی ها | AMD Rome 32 Cores |
---|
at_max-power | Efficiency: Gold, Output Watts: 315W, Type: Single PSU |
---|
ابعاد | 1.75" x 19.00" x 15.50" |
---|
