| برند محصول | 3Ware |
|---|---|
| مدل محصول | 9690SA-8I-SGL |
| فرم فاکتور (قالب) | Low Profile |
| نوع | SATA/SAS |
| حافظه کش | 512MB DDR2 533 |
| اتصالات داخلی | 2x SFF-8087 mini-SAS |
| نوع رابط | PCI-Express x8 |
| نرخ انتقال | Up to 3Gb/s |
| RAID | RAID 0/1/5/6/10/50 |
| سیستم عامل پشتیبانی شده | Microsoft Windows Vista/2003/XP/2000, Red Hat Linux, SuSE Linux, Fedora Linux, 2.4 Linux kernel, 2.6 Linux kernel, FreeBSD; 32/64-bit driver support for Windows, Linux and FreeBSD. |
| ویژگی ها | — 3ware BIOS Manager (3BM) - easy to use BIOS configuration tool, — 3ware Disk Manager 2 - browser-based management tool, 512MB DDR2 533 memory with ECC protection, 8th-generation StorSwitch non-blocking switched architecture, Array/Drive Status and drive identification LED support, Auto carving allows LUNs > 2TB to be divided into multiple units for legacy operating systems limited to 2TB max. per LUN, Battery Backup Unit (BBU) with remote battery support, Bootable array support for greater fault tolerance of your OS, Command Line Interface (CLI) - scriptable configuration tool, Complete configuration management suite, Drive activity LED support, Drive insertion and removal notification, Dynamic sector repair for robust data protection, Emergency Flash Recovery protects against failed firmware upgrade, Enclosure management via I2C and SES 2.0, Hot-swap and hot-spare support for data availability, Multiple logical unit sizes and RAID levels on one card, Multiple SAS/SATA RAID sets, On-board I/O RISC processor and RAID offload provides true hardware RAID — SCSI device driver model to take advantage of SAS or inexpensive Serial ATA drives, Online Capacity Expansion (OCE), RoHS 6 of 6 and WEEE compliant, S.M.A.R.T. disk drive monitoring for reliability, SMTP support for email/pager notification, SNMP support, Staggered Drive Spin Up, Support for greater than 2TB volumes, Variable stripe size for performance tuning by application, Write journaling for improved performance and data protection against accidental drive removal |
