انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | LSI |
|---|---|
| سری محصول | MegaRAID |
| مدل محصول | 9460-16i |
| شماره قطعه | 05-50011-00 |
| فرم فاکتور (قالب) | Low Profile |
| نوع | SAS/SATA/PCIe(NVMe) |
| حافظه کش | 4GB DDR4 2133 |
| اتصالات داخلی | 4x Mini-SAS HD x4 SFF-8643 |
| نوع رابط | PCI-Express 3.1 x8 |
| نرخ انتقال | 12 Gb/s SAS-3 and 8 GT/s PCIe Gen 3 (NVMe) Compliant |
| RAID | RAID 0/1/5/6/10/50/60 |
| سیستم عامل پشتیبانی شده | Microsoft Windows. Contact Oracle support for Oracle Solaris driver or software support |
| ویژگی ها | Add more protection and peace of mind with CacheVault flash cache protection, Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS , Balance protection and performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, and 60, Broadcom's Tri-Mode SerDes Technology enables the operation of NVMe, SAS or SATA devices in a single drive bay, allowing for endless design flexibility., Cache Protection: CacheVault CVPM05, Connect up to 255 SAS/SATA devices or 24 NVMe devices per controller, Data center, cloud and high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection, flexibility and performance today&apo, Fits into rack-mounted servers with low-profile form factor and side-mounted SAS connectors, I/O Processor / SAS Controller: SAS3516 dual-core RAID-on-Chip (ROC), Lifecycle: Active, Operating Temperature: 0 degree C to 55 degree C, Operating Voltage (V): +12V +/-8%, 3.3V +/-9%, RAID Management Software: LSI Storage Authority (LSA), StorCLI (command-line interface), HII (UEFI Human Interface Infrastructure), Regulatory Certifications:, Support critical, high-bandwidth applications with PCIe 3.1 connectivity |
| ابعاد | 6.13"x2.71" |
