برند محصول | ایسوس (ASUS) |
---|---|
مدل محصول | ROG-THOR-1600T-GAMING |
شماره قطعه | 90YE00K0-B0AA00 |
نوع | ATX 12V |
ماژولار | ماژولار کامل |
بهره وری انرژی | 80 Plus Titanium |
بیشترین توان | 1600W |
خروجی | +3.3V +5V +12V -12V +5Vsb |
ولتاژ ورودی | 100 - 240V |
اتصالات | CPU 4+4-pin x 2, MB 24/20-pin x 1, PCI-E 16-pin x 1, PCI-E 6+2-pin x 10, Peripheral x 6, SATA x 12 |
اتصال اصلی | 24Pin |
اتصال PCI-Express | 10X 6+2-Pin |
اندازه فن | 135 میلیمتر |
محافظت در مقابل ولتاژ بیش از حد مجاز | بلی |
ویژگی ها | • 135MM PWM FAN, • 80 PLUS TITANIUM CERTIFICATION, • AURA SYNC, • DIGITAL POWER CONTROL. A digital controller provides precise control over the GaN power array, facilitating lightning-fast response to load changes., • GAN MOSFETS. Boasting lower switching losses and improved efficiency compared to conventional silicon transistors, GaN FETs allow the 1600W Thor to swing massive amounts of current without being, • LAMBDA A++ CERTIFICATION, • OLED display monitors power draw in real time., • PCIE GEN 5.0 READY. Each ROG Thor 1600W Titanium PSU is bundled with a 16-pin PCIe cable that can pipe up to 600W of power to PCIe Gen 5.0 graphics cards. Get ready for the future of power deliv, • ROG HEATSINKS. Integrated ROG heatsinks have 2x more volume than traditional designs, resulting in 20% lower temperatures inside the PSU, further extending component lifespan., • SLEEVED CABLES. A range of sleeved cables are bundled with Thor, and we also provide a 20% CableMod discount. |
محتویات بسته بندی | 16-pin PCI-E Cable x 1 (675mm), Addressable RGB Cable x 1 (800mm), Cable Tie x 12, Chassis Screws Package x 1, CPU Cable x 2 (650mm), Motherboard Power Cable x 1 (610mm), PCI-E 1-to-1 Cable x 6 (675mm), PCI-E 1-to-2 Cable x 2(675+75mm), Peripheral 1-to-2 Cable x3(450+120mm), Power Cord x 1, ROG Cable Tie x 6, ROG Sticker x 1, SATA 1-to-4 Cable x 3(400+120+120+120mm), User Manual x 1 |
ابعاد | 190 x 150 x 86 mm |
بیشرین طول منبع تغذیه | 190 mm |
وزن | 2.69 کیلوگرم |
