انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | ASUS |
|---|---|
| مدل محصول | WS-C621ESage |
| فرم فاکتور (قالب) | EEB |
| نوع پردازنده | Dual Intel Socket P (LGA 3647) for Intel Xeon Scalable Processors Family (205W) |
| نوع سوکت پردازنده | دوگانه LGA3647 |
| چیپ ست North Bridge | Intel C621 |
| استاندارد DDR4 | DDR4 2666 / 2400 MHz RDIMM, LR-DIMM Memory |
| بیشترین حافظه قابل پشتیبانی | 768GB |
| PCI Express 3.0 x16 | 2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8), 2 x PCIe 3.0 x16 (x8 mode), 3 x PCIe 3.0 x16 (x16 mode) |
| SATA | 10 x SATA 6.0Gb/s |
| SATA RAID | 0/1/5/10 |
| چیپ ست گرافیکی Onboard | Aspeed AST2500 with 64MB VRAM |
| چیپ ست LAN | Intel I210-AT |
| سرعت LAN | 10/100/1000Mbps |
| چیپ ست LAN دوم | Intel I210-AT |
| سرعت LAN دوم | 10/100/1000Mbps |
| پورت RJ45 | 2 x RJ45 |
| پورت PS2 | 1 x PS/2 keyboard/mouse port |
| ویژگی ها | 2-Way Overclocking Performance unlocks the full power of the dual Xeon processors, ASMedia SATA 6Gb/s controller: 2 x SATA 6Gb/s port (s), 4 x U.2 connector, 1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode), ASMedia USB 3.1 Gen 2 controller: 2 x USB port (s) (2 at back panel , Type-A + USB Type-CTM), complete-it-infrastruct, designed-for-dual-7th-g, Industry-leading 7.1-channel HD audio enhanced by ASUS exclusive Realtek S1220A featuring DTS Headphone:X and driven by Japanese capacitors for warm, immersive sound, Intel C621 Chipset: 4 x USB 2.0 port (s) (2 at back panel , 2 at mid-board), Intel C621 Chipset: 8 x SATA 6Gb/s port (s), Support Raid 0, 1, 5, 10, Next-gen transfer speeds with up to 32 Gbps M.2 and U.2, plus up to 10 Gbps USB 3.1 Type-A and Type-C connections, Patent-pending SafeSlot features an injection molding process that integrates metal framing for stronger, firmly anchored PCIe slots built for heavyweight GPUs, Storage:, USB Ports:, Winner of 18 #1 Benchmark World Records by the Standard Performance Evaluation Corporation (SPEC) |
| ابعاد (عرض*ارتفاع*طول) | 12.0" x 13.0" |
