| برند محصول | Planet |
|---|---|
| مدل محصول | WGSW-24040R |
| نوع مدیریت شبکه | Managed |
| متد سوییچ | Store and Forward |
| پورت اصلی | 24 |
| پورت های اصلی | 24x RJ45 + 4x SFP |
| سرعت پورت اصلی | 10/100/1000Mbps |
| پورت Mirroring | Many to 1, TX/RX/Both |
| پروتکل ها | IPv4 software static routing, IPv6 software static routing, MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, Routing Protocols:, RSTP, IEEE 802.1w Rapid Spanning Tree Protocol, Spanning Tree Protocol:, STP, IEEE 802.1D Spanning Tree Protocol |
| لایه | 2 |
| QoS | 8-level priority for switching:, 802.1p priority, 802.1Q VLAN tag, DSCP / ToS field in IP packet, Port number, Traffic classification based, strict priority and WRR |
| LACP | بلی |
| پشتیبانی از VLan | 802.1Q tagged based VLAN, IP subnet-based VLAN, MAC-based VLAN, MVR (Multicast VLAN registration), Private VLAN Edge (PVE), Protocol-based VLAN, Q-in-Q tunneling, Up to 255 VLAN groups, out of 4095 VLAN IDs, Voice VLAN |
| حافظه Buffer | 1392KB |
| Jumbo frame | 9 KB |
| جدول MAC آدرس | 8K |
| دکمه | Reset |
| LED | 10/100/1000 Link / Act per RJ45 port, 100/1000 Link / Act per SFP port, Power, fan alert |
| توان | 48V DC at 0.6A, DC voltage range: 30 - 60V, Max. 21.0 watts / 71.652 BTU |
| دما | -20 - 70 C, 0 - 50 C |
| رطوبت | 20% - 95%, Non-condensing |
| ویژگی ها | 100 - 240V AC / 48V DC dual power redundancy, 24-port 10/100/1000BASE-T RJ45 copper, 4 100/1000BASE-X mini-GBIC/SFP slots, compatible with 100BASE-FX SFP, Active-active redundant power failure protection, Backup of catastrophic power failure on one supply, BOOTP and DHCP for IP address assignment, Cable diagnostic technology provides the mechanism to detect and report potential cabling issues, DHCP Relay and DHCP Option82, Fault tolerance and resilience, Four RMON groups (history, statistics, alarms, and events), High performance of Store-and-Forward architecture, and runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth, IGMP snooping port filtering, IPv4 and IPv6 dual stack management, IPv6 IP Address / NTP / DNS management and ICMPv6, Layer 2 Features:, Layer 3 IP Routing Features:, Link Layer Discovery Protocol (LLDP), Loop protection to avoid broadcast loops, Management:, MLD snooping port filtering, Multicast:, MVR (Multicast VLAN Registration), NTP (Network Time Protocol), Physical Port:, PLANET Smart Discovery Utility, Port mirroring to monitor the incoming or outgoing traffic on a particular port, Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex), Provides port mirror (many-to-1), Querier mode support, Redundant Power System:, RS-232 DB9 console interface for basic management and setup, Storm control support, Supports IGMP snooping v1, v2 and v3, Supports Link Aggregation, Supports maximum 32 software static routes and route summarization, Supports MLD snooping v1 and v2, Supports Spanning Tree Protocol, Supports VLAN, Switch Management Interfaces, System Maintenance, User privilege levels control |
| امنیت | Access Control List, Authentication:, Auto DoS rule to defend DoS attack, Built-in RADIUS client to co-operate with RADIUS server, DHCP Snooping to filter distrusted DHCP messages, Dynamic ARP Inspection, IEEE 802.1x port-based/MAC-based network access authentication, IP address access management to prevent unauthorized intrude, IP Source Guard prevents IP spoofing attacks, IPv4/IPv6 IP-based ACL, MAC-based ACL, Port security for source MAC address entries filtering, RADIUS / TACACS+ users access authentication, Source MAC/IP address binding, TACACS+ login users access authentication |
| ابعاد | 1.75" x 17.32" x 7.87" |
| وزن | 6.30 پوند |
