| برند محصول | Planet |
|---|---|
| مدل محصول | GS-4210-16P2S |
| نوع مدیریت شبکه | Managed |
| متد سوییچ | Store and Forward |
| پورت اصلی | 16 |
| پورت های اصلی | 16x 10/100/1000BASE-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ Injector, 1x RJ45 console interface for basic management and setup, 2x 100/1000BASE-X mini-GBIC/SFP slots for SFP type auto detection |
| پورت Mirroring | بلی |
| PoE | بلی |
| QoS | بلی |
| SNMP | بلی |
| LACP | بلی |
| پشتیبانی از VLan | بلی |
| Jumbo frame | 9 KB |
| جدول MAC آدرس | 8K |
| LED | 10/100/1000T RJ45 Interfaces (Port 1 to Port 48):, 100/1000 Mbps SFP Interfaces (Port 49 to Port 52):, System: Power (Green) |
| توان | Power Consumption / Dissipation: 500 watts (max.) / 1706 BTU, Power Requirements: 100-240V AC, 50/60 Hz, 15A |
| دما | Operating temperature: 0 degree to 50 degree C (32 degree to 122 degree F), Storage temperature: -10 degree to 70 C (-14 degree to 158 degree Fahrenheit) |
| رطوبت | 5% - 95%, Non-condensing |
| استانداردها | IEEE 802.1AB LLDP, IEEE 802.1D Spanning Tree (STP), IEEE 802.1p Class of Service, IEEE 802.1Q VLAN Tagging, IEEE 802.1s Multiple Spanning Tree (MSTP), IEEE 802.1w Rapid Spanning Tree (RSTP), IEEE 802.1x Port Authentication Network Control, IEEE 802.3 10BASE-T, IEEE 802.3ab Gigabit 1000T, IEEE 802.3ad port trunk with LACP, IEEE 802.3af Power over Ethernet, IEEE 802.3at Power over Ethernet Plus, IEEE 802.3u 100BASE-TX, IEEE 802.3x Flow Control, IEEE 802.3z Gigabit SX/LX, RFC 1112 IGMP version 1, RFC 2068 HTTP, RFC 2236 IGMP version 2, RFC 3376 IGMP version 3, RFC 768 UDP, RFC 791 IP, RFC 792 ICMP, RFC 793 TFTP |
| ویژگی ها | - BPDU Guard, - Broadcast, Unknown Unicast, and Unknown Multicast, - DSCP / IP Precedence of IPv4 / IPv6 packets, - IEEE 802.1D Spanning Tree Protocol (STP), - IEEE 802.1p CoS, - IEEE 802.1Q tagged VLAN, - IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN, - IEEE 802.1w Rapid Spanning Tree Protocol (RSTP), - IEEE 802.3ad Link Aggregation Control Protocol (LACP), - PoE usage threshold control, - Protocol VLAN, 1 x RJ45 console interface for switch basic management and setup, 16 x 10/100/1000BASE-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ Injector, 2 x 100/1000Base-X mini-GBIC/SFP slots, SFP type auto detection, Auto detects powered device (PD), Circuit protection prevents power interference between ports, Cisco ether-Channel (Static Trunk), Complies with IEEE 802.3at Power over Ethernet Plus, end-span PSE, High performance Store and Forward architecture, broadcast storm control, runt / CRC filtering that eliminates erroneous packets to optimize the network bandwidth, Ingress / Egress Rate Limit per port bandwidth control, Intelligent PoE features, Layer 2 Features:, PD alive check, PD classification detection, Per PoE port power limitation, Per port PoE function enable/disable, Physical Port:, PoE management, PoE port power feeding priority, PoE schedule, Power over Ethernet:, Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex), Provides port mirror (many-to-1), Quality of Service:, Remote power feeding up to 100 meters, Storm control support, Strict priority and Weighted Round Robin (WRR) CoS policies, Supports Link Aggregation, Supports PoE power up to 36 watts for each PoE port, Supports Spanning Tree Protocol, Supports VLAN, Total PoE power budget control, Traffic classification, Up to 16 ports of IEEE 802.3af / 802.3at devices powered |
| امنیت | Built-in RADIUS client to co-operate with RADIUS server, DHCP Snooping and DHCP Option82, IEEE 802.1X Port Based Network Access Control, MAC filter, RADIUS/TACACS+ user access authentication, Static MAC address, STP BPDU guard, BPDU filtering and BPDU forwarding |
| ابعاد | 1.77" x 17.52" x 8.15" |
| وزن | 6.17 پوند |
