انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | Netis Systems |
|---|---|
| مدل محصول | ST3328 24FE |
| شماره قطعه | ST3328 |
| نوع مدیریت شبکه | Managed |
| متد سوییچ | Store and Forward |
| پورت اصلی | 24 |
| پورت های اصلی | 1x RS232 Console port, 24x 10/100 Mbps RJ45 port, Auto-Negotiation, Auto MDI / MDIX, 4x Combo port: 4x 10/100/1000 Mbps RJ45 port + 4x SFP slot (Mini-GBIC), 1000 full mode supported |
| سرعت پورت اصلی | 10/100/1000Mbps |
| پورت Mirroring | بلی |
| QoS | 8 priority queues, Strict priority (SP), Weighted Round Robin (WRR), SP+WRR CoS policies, Traffic-policing policies |
| SNMP | بلی |
| پشتیبانی از VLan | GVRP protocol for VLAN Management, IEEE 802.1Q Tag-based VLAN, Q-in-Q tunneling, Up to 4K VLANs groups, out of 4094 VLAN IDs |
| حافظه Buffer | 4MB |
| جدول MAC آدرس | 8K |
| کیس | فلزی |
| LED | PWR, SYS, 1X-24X 10/100M, 1X-24X LNK / ACT, 25X-28X 10/100/1000M, 25X-28X LNK / ACT |
| توان | 100-240V AC, 50/60Hz |
| دما | Operating temperature: 0 degree to 50 degree C (32 degree to 122 degree F), Storage Temperature: -40 ~ 158 degree Fahrenheit |
| رطوبت | Operating Humidity: 90% maximum relative humidity, non-condensing, Storage Humidity: 5% ~ 95% non-condensing |
| استانداردها | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z Gigabit SX/LX, IEEE 802.3ab Gigabit 1000Base-T, IEEE 802.3ae 10 Gigabit Ethernet, IEEE 802.3x Flow Control and Back Pressure, IEEE 802.3ad Por |
| ویژگی ها | 12.8 Gbps switching fabric capacity, 24 10/100 Mbps Ethernet ports, 4 Combo Gigabit ports supporting both copper and SFP connections, IEEE 802.3x compliant Flow Control support for full duplex, Provides high performance of Store-and-Forward architecture, broadcast storm control, Supports DHCP Snooping, Relay and Option 82, Supports IEEE 802.1Q VLAN, Supports IGMP snooping v1, v2 and v3, Supports LLDP, DLDP, Supports powerful security functions like ACL, dynamic ARP inspection, IP-MAC-Port-VID Binding, Supports SNMP v1/v2c/v3 , SSH v1/v2 switch management, Supports Spanning Tree Protocol |
| امنیت | Access Control List (ACL), Broadcast Storm Control, Dynamic ARP Inspection, IEEE 802.1X Port Based Network Access Control, MAC Binding, RADIUS / TACACS+ users access authentication |
| محتویات بسته بندی | 1 x Power Cord, 1 x Quick Installation Guide, 1 x RS232 Console Cable, 1 x ST3328, 2 x Rackmount Brackets and the Fittings |
| ابعاد | 1.73" x 17.01" x 9.84" |
