Netis Systems
ST3324GF
ST3306
Desktop
Unmanaged
Store and Forward
24
1x RS232 Console port, 22x 10/100/1000Mbps RJ45 port, Auto-Negotiation, Auto MDI/MDIX, 2x Combo port: 2x 10/100/1000Mbps RJ45 port + 2 * SFP slot(Mini-GBIC), 1000 full mode supported
10/100/1000Mbps
بلی
8 priority queues, Strict priority(SP), Weighted Round Robin(WRR), SP+WRR CoS policies, Traffic-policing policies
GVRP protocol for VLAN Management, IEEE 802.1Q Tag-based VLAN, Up to 4K VLANs groups, out of 4094 VLAN IDs
4MB
8K
فلزی
PWR, CPU, 1-24 1000M, 1-24 LNK/ACT
100-240V AC, 50/60Hz
Operating Humidity: 90% maximum relative humidity, non-condensing, Storage Humidity: 5%~90% non-condensing
IEEE 802.1p, IEEE 802.1q, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, IEEE 802.1x, IEEE 802.3 10BASE-T, IEEE 802.3z 1000Base-LX/SX, IEEE 802.3x, IEEE 802.3ad,
22 10/100/1000Mbps Ethernet ports, 2 Combo Gigabit ports supporting both copper and SFP connections, 48 Gbps switching fabric capacity, Back Pressure Flow Control, Cisco ether-Channel (Static Trunk), Console/Telnet Command Line Interface, DHCP, DHCP Option 82, DHCP Relay, DHCP Snooping, DLDP (Device Link Detection Protocol), Egress and Ingress Bandwidth Control, Flow Control, flow mirroring, IEEE 802.3ad LACP (Link Aggregation Control Protocol), IEEE 802.3x PAUSE frame Flow Control, Full-Duplex mode, IGMP Snooping v1/v2/v3, Link Aggregation, LLDP(Link Layer Discovery Protocol), Loopback Detection, MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN), Multicast VLAN Registration (MVR), Multicast:, Port mirroring, Provides high performance of Store-and-Forward architecture, broadcast storm control, Provides SSH encryptions, RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol), SNMP v1/v2c/v3, Spanning Tree Protocol instances: 254, SSH v1/v2, STP, IEEE 802.1D (Classic Spanning Tree Protocol), Supports DHCP Snooping, Relay and Option 82, Supports IEEE 802.1Q VLAN, Supports IGMP snooping v1, v2 and v3, Supports Link Aggregation, Supports LLDP, DLDP, Supports Port Mirroring, Flow mirroring, Supports powerful security functions like ACL, dynamic ARP inspection, IP-MAC-Port-VID Binding, Supports SNMP v1/v2c/v3 , SSH v1/v2 switch management, Supports Spanning Tree Protocol, Up to 8 ports per trunk group, Up to 8 Trunk groups, Web
Access Control List(ACL), Broadcast Storm Control, Dynamic ARP Inspection, IEEE 802.1X Port Based Network Access Control, IP-MAC-Port-VID Binding, RADIUS / TACACS+ users access authentication, SSH encryptions
1 x Power Cord, 1 x RS232 Cord, 1 x ST3324GF, 2 x Brackets
17.13" x 9.84" x 1.73" (L x W x H)
