انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | TP-Link |
|---|---|
| سری محصول | Jetstream |
| مدل محصول | TL-SG3210 |
| فرمت | Rack |
| نوع مدیریت شبکه | Managed |
| پورت اصلی | 8 |
| پورت های اصلی | 8x RJ45 + 2x SFP |
| سرعت پورت اصلی | 10/100/1000Mbps |
| پورت Mirroring | بلی |
| لایه | 2 |
| QoS | بلی |
| SNMP | بلی |
| LACP | بلی |
| پشتیبانی از VLan | بلی |
| حافظه Buffer | 512KB |
| Jumbo frame | 10KB |
| جدول MAC آدرس | 8K |
| کابل کشی | 1000BASE-X: MMF, SMF, 100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m), 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| توان | 100~240VAC, 50/60Hz |
| دما | 0ºC to 40ºC (32ºF to 104ºF) |
| رطوبت | 10% - 90%, Non-condensing |
| ویژگی ها | - Voice VLAN, 1 Console Port, 2 1000Mbps SFP Slots, 8 10/100/1000Mbps RJ45 Ports, 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group), 802.3x Flow Control, Access Control List:, Bandwidth/Backplane: 20Gbps, BPDU Filtering/Guard, CPU Monitoring, DHCP/BOOTP Client,DHCP Filtering, Firmware Upgrade: TFTP & Web, GARP/GVRP, IGMP Snooping v1/v2/v3, Integrated NDP/NTDP feature, Interface, L2 Features:, L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID;, Loop Back Detection, Management VLAN configuration, Management:, Packet Forwarding Rate: 101.19Mpps, Port isolation, Port mirroring, Port/ MAC/Protocol-based VLAN, Port/Flow- based Rate Limiting, Quality of Service:, Queue scheduling: SP, WRR, SP+WRR, RMON (1, 2, 3, 9 groups), SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs, Spanning Tree STP/RSTP/MSTP, Support 4 priority queues, Support 802.1p CoS/DSCP priority, Support IEEE802.1Q with 4K VLAN groups and 4K VIDs, SYSLOG & Public MIBS, System Diagnose: VCT, TC/Root Protect, Time Range Based, Time Setting: SNTP, VLAN:, Web-based GUI and CLI management |
| امنیت | Broadcast/Multicast/Unknown-unicast Storm Control, DoS Defence, Dynamic ARP Inspection, IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN, IP-MAC-Port-VID Binding, Port security, SSH v1 / v2, SSL v2/v3/TLSv1 |
| محتویات بسته بندی | Switch; Power Cord; Quick Installation Guide;Resource CD; Rackmount Kit; Rubber Feet |
| ابعاد | 11.7" x 7.1" x 1.7" |
| وزن | 5.15 پوند |
