TRENDnet
TPE-P521ES-V1
Managed
5
1x Gigabit PoE+ input port, 2x Gigabit PoE output ports, 2x Gigabit ports
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex), Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex), Gigabit Ethernet: 2000 Mbps (full duplex)
بلی
TCP/IP
بلی (PoE+)
512KB
9 KB
2K
18W PoE Budget with IEEE 802.3at (30W) input power, 8W PoE Budget with IEEE 802.3af (15.4W) input power, IEEE 802.3af Type 1 PoE PD Class 0, IEEE 802.3at (30W) or IEEE 802.3af (15.4W) PoE input only (no external power supply), IEEE 802.3at Type 2 PoE PD Class 4, Max. Consumption 2.4W (without PoE load), Max. Consumption 20.4W (with max PoE load), Over current / short circuit protection, PD auto classification, PoE Mode A: Pins 1,2 for power and pins 3,6 for power, PoE:, Power:
Operating Temperature: 0 ~ 45 C (32 ~ 113 degree Fahrenheit)
Operating Humidity: Max. 95% non-condensing
IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
1 x Gigabit PoE+ input port, 10 Gbps switching capacity (2 Gbps per port with full duplex), 18W PoE power budget, 2 x Gigabit PoE output ports, 2 x Gigabit ports, Bandwidth control per port, Compact fanless design, Easy-to-use web-based management interface, IEEE 802.1p QoS with queue scheduling support, Supports LACP, VLAN, QoS, STP, RTSP and IGMP Snooping, Voice VLAN for VoIP applications, Wall mountable metal housing
Quick Installation Guide (QIG), TPE-P521ES
1.20" x 5.90" x 3.81"
0.82 پوند
