| برند محصول | TRENDnet |
|---|---|
| مدل محصول | TPE-3018LS |
| فرمت | Desktop |
| نوع مدیریت شبکه | Smart |
| پورت اصلی | 18 |
| پورت های اصلی | 16x RJ45 + 2x SFP |
| سرعت پورت اصلی | 10/100/1000Mbps |
| PoE | 802.3at: up to 30W per port (ports 1-16), Over current/short circuit protection, PD alive check, PoE budget: 220W, PoE Mode A: Pins 1,2 and pins 3,6 for power, PoE power scheduling |
| پشتیبانی از VLan | 802.1Q Tagged VLAN, MAC-based VLAN, Multiple management VLAN assignment, Surveillance VLAN, Up to 256 VLAN groups, ID Range 1-4094, Voice VLAN |
| Jumbo frame | 10KB |
| جدول MAC آدرس | 8K |
| توان | Input: 100 - 240V AC, 50/60 Hz, Max. consumption: 14W (No PoE load) |
| دما | Operating Temperature: 0 ~ 45 C (32 ~ 113 degree Fahrenheit) |
| رطوبت | Operating Humidity: Max. 95% non-condensing |
| استانداردها | IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, |
| امنیت | 802.1X port-based authentication (Local user database, RADIUS, Guest VLAN), Access Control List (ACL), Change IP camera administrator user name and password, Change IP camera IP address settings, Denial of Service (DoS) prevention, Device discovery for ONVIF compliant devices such as IP cameras or NVRs, DHCP Snooping / Option 82, Head-of-line (HoL) blocking prevention, IP Source Guard / IP-MAC-Port-VLAN binding, IPv4 (IP Protocol, TCP/UDP Port, 802.1p, DSCP, TCP flag, ICMP type, ICMP code), Loopback detection, MAC Address (VLAN ID, EtherType, 802.1p), Port Security/MAC address learning restriction, Protected ports, Storm control (broadcast, unknown multicast, unknown unicast, min: 16Kbps), Surveillance Mode (ONVIF), Surveillance mode GUI for simplified configuration and network monitoring, Upgrade IP camera firmware, Upload virtual maps |
| محتویات بسته بندی | Power cord (1.5m/5 ft.), Quick Installation Guide (QIG), Rack Mount Kit, TPE-3018LS |
| ابعاد | 17.30" x 9.80" x 1.74" |
| وزن | 6.45 پوند |
