انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | HP |
|---|---|
| سری محصول | ProCurve |
| مدل محصول | 4108GL |
| شماره قطعه | J4865A |
| پورت اصلی | 24 |
| سرعت پورت اصلی | 10/100/1000Mbps |
| پروتکل ها | Cisco Fast EtherChannel (FEC), DHCP Relay, HTML and telnet management, RFC 1213 MIB II, RFC 1492 TACACS+, RFC 1493 Bridge MIB, RFC 1542 BootP, RFC 2021 RMON probe configuration (RMON v2), RFC 2030 Simple Network Time Protocol (SNTP) v4, RFC 2096 IP Forwarding Table MIB, RFC 2138 RADIUS, RFC 2236 IGMP v1/v2/v3, RFC 2613 SMON, RFC 2618 RADIUS Client MIB, RFC 2620 RADIUS Accounting MIB, RFC 2665 Ethernet MIB, RFC 2668 802.3 MAU MIB, RFC 2674 802.1p and IEEE 802.1Q Bridge MIB, RFC 2737 Entity MIB, RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events), RFC 2863 Evolution of Interface, RFC 2866 RADIUS accounting, RFC 768 UDP, RFC 783 TFTP, RFC 792 ICMP, RFC 793 TCP, RFC 826 ARP, RFC 854 Telnet, RFC 951 BootP, Secure Sockets Layer (SSL), SNMPv1/v2c/v3, SSHv1/SSHv2 Secure Shell |
| پشتیبانی از VLan | بلی |
| حافظه Buffer | 512 KB flash, 512 KB SRAM, Packet buffer size: 1MB at Module, 8MB flash, 32MB SDRAM at Fabric module |
| توان | Current: 8.2 A /3.8 A, Frequency: 50/60 Hz, Power: 630 W, Voltage: 100-127 VAC/200-240 VAC |
| دما | 0° to 55° C (32° to 131° F) |
| رطوبت | 15 % to 95 % at 104 °F (40 °C), noncondensing |
| استانداردها | IEEE 802.1D Spanning Tree Protocol, IEEE 802.1p Priority, IEEE 802.1Q GVRP, IEEE 802.1Q VLAN Tagging, IEEE 802.1w Rapid Convergence Spanning Tree, IEEE 802.1X Network Login, IEEE 802.3ad Link Aggregation Control Protocol (LACP), IEEE 802.3x Flow Control |
| ویژگی ها | 1 RS-232C DB-9 console port, 8 open module slots, 802.1w Rapid Convergence Spanning Tree Protocol, 802.3ad Link Aggregation, Basic IP routing, Dual flash images: provide independent primary and secondary OS files for backup while upgrading, Fast Path Technology: wire-speed switching of intra-module traffic for up to 31.9 million pps throughput; fully loaded 8-slot chassis capable of switching 255 million pps, Fast switch fabric: inter-module traffic switching of up to 2.97 million pps, Friendly port names: allow assignment of descriptive names to ports, Group VLAN Registration Protocol (GVRP), Hot-swappable modules, Optional redundant power supply, Port security: prevents unauthorized access using MAC address lockdown, Ports:, ProCurve/IEEE Auto-MDIX, RMON: provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events, Routing table size: 8000 entries, Stacking capability, Supports a maximum of 192 10/100 ports or 160 Gigabit ports and 16 mini-GBICs, or a combination, Switch fabric speed: 36.6 Gbps, TACACS+: eases switch management security administration by using a password authentication server, Traffic prioritization (IEEE 802.1p), VLAN support and tagging |
| امنیت | Secure access to manage the ProCurve 4100gl series: all access methods—CLI, GUI, or MIB—are securely encrypted through SSHv2, SSL, and/or SNMPv3, Secure Shell (SSHv2), Secure Sockets Layer (SSL) |
| ابعاد | 17.4" x 15.3" x 8.8" |
| وزن | 20.7 پوند |
