برند محصول |
Supermicro
|
مدل محصول |
SYS-F627R2-F73
|
نوع |
Rackmount
|
فرم فاکتور (قالب) |
4U
|
نوع پردازنده |
E5-2600 v2, Intel Xeon E5-2600
|
سوکت پردازنده |
LGA2011
|
بیشترین تعداد پردازنده |
2
|
at_installed-cpu |
بدون پردازنده
|
چیپ ست North Bridge |
Intel C602
|
at_memory-type-supported |
DDR3 1866/1600/1333/1066/800
|
اسلات های حافظه |
8x 240Pin
|
میزان حافظه نصب شده |
بدون حافظه رم
|
at_max-memory-supported |
256GB DDR3 (RDIMM), 512GB DDR3 LRDIMM, 64GB DDR3 (UDIMM)
|
at_installed-hdd |
بدون حافظه ذخیره سازی
|
SAS |
8x SAS2 (6Gbps) ports, SAS2 via LSI 2308, SW RAID 0, 1, 10 support
|
SATA RAID |
SATA2 (3Gbps) with RAID 0/1/5/10, SATA3 (6Gbps) with RAID 0/1
|
at_hot-swap-bays |
8x 2.5" Hot-swap SAS/SATA HDD Bays + 4x 2.5" Hot-swap SATA HDD Bays
|
at_gpu-vpu |
Matrox G200eW
|
VGA |
1
|
LAN اول |
Intel 82574L 2x Port Gigabit Ethernet
|
حداکثر سرعت LAN |
2x 10/100/1000Mbps
|
پورت RJ45 |
1x RJ45 Dedicated IPMI LAN port, 2x RJ45 Gigabit Ethernet LAN ports
|
at_pci-express |
1x PCI-E 3.0 (x16) (LP) via riser card
|
USB پشتی |
2
|
پورت COM |
1x Fast UART 16550 port
|
پشتیبانی ECC |
بلی
|
رجیستر شده |
بلی
|
ویژگی ها |
1x SAS2 / SATA backplane, 2x Network activity LEDs, 8x 8cm heavy duty fans with air shroud and PWM fan speed control, Buttons, Front Panel, IPMI, IPMI 2.0 with virtual media over LAN and KVM-over-LAN support, LEDs:, Nuvoton WPCM450 BMC, Power fail LED, Power On/Off button, Power status LED, Support for Intelligent Platform Management Interface v.2.0, System Overheat LED, System Reset button
|
at_max-power |
1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2
|
ابعاد |
6.96" x 17.63" x 29" (H x W x D)
|
