برند محصول |
Supermicro
|
مدل محصول |
SYS-6027TR-H71QRF
|
نوع |
Rackmount
|
فرم فاکتور (قالب) |
2U
|
نوع پردازنده |
E5-2600 v2, Intel Xeon E5-2600
|
سوکت پردازنده |
LGA2011
|
بیشترین تعداد پردازنده |
2
|
at_installed-cpu |
بدون پردازنده
|
چیپ ست North Bridge |
Intel C602
|
at_memory-type-supported |
DDR3 1866/1600/1333/1066/800
|
اسلات های حافظه |
8x 240Pin
|
میزان حافظه نصب شده |
بدون حافظه رم
|
at_max-memory-supported |
256GB DDR3 (RDIMM), 512GB DDR3 LRDIMM
|
at_installed-hdd |
بدون حافظه ذخیره سازی
|
SAS |
8x SAS2 ports (6Gbps), LSI 2108 SAS (6Gbps) w/ Hardware RAID support, RAID 0, 1, 5, 6, 10, 50 support
|
SATA RAID |
RAID 0/1/5/10
|
Serial ATA |
2x SATA 600 + 5x SATA 300
|
at_hot-swap-bays |
3x Hot-swap 3.5" SATA3/SAS2 HDD trays
|
at_gpu-vpu |
Matrox G200eW
|
VGA |
1
|
LAN اول |
Intel I350
|
حداکثر سرعت LAN |
2x 10/100/1000Mbps
|
پورت RJ45 |
1x RJ45 Dedicated IPMI LAN port, 2x RJ45 Gigabit Ethernet LAN ports
|
at_pci-express |
1x PCI-E 3.0 (x16) Low-profile slot
|
USB پشتی |
2
|
پورت COM |
1x Fast UART 16550 port
|
پورت های دیگر |
1x External QSFP Infiniband connector
|
پشتیبانی ECC |
بلی
|
رجیستر شده |
بلی
|
ویژگی ها |
2x Network activity LEDs, 4x 8cm heavy duty PWM fans with optimal fan speed control, Buttons, Front Panel, HDD activity LED, Infiniband, IPMI, IPMI 2.0 with virtual media over LAN and KVM-over-LAN support, LEDs:, Mellanox ConnectX-3 QDR Infiniband 40Gbps Controller, Nuvoton WPCM450 BMC, Power On/Off button, Power status LED, Support for Intelligent Platform Management Interface v.2.0, System Reset button, UID button, Universal Information (UID) LED
|
at_max-power |
1620W high-efficiency redundant power supply w/ PMBus, 80PLUS Platinum
|
ابعاد |
3.47" x 17.25" x 28.5" (H x W x D)
|
