انتخاب هوشمندانه سخت افزار و تجهیزات شبکه
| برند محصول | Hikvision |
|---|---|
| سری محصول | AcuSense |
| مدل محصول | DS-2CD2343G2-IU |
| نوع | Turret |
| نوع لنز | Aperture: F1.6, Lens Mount: M12, Lens Type & FOV: 2.8 to 12 mm, horizontal FOV 95.8° to 29.2°, vertical FOV 50.6° to 16.4°, diagonal FOV 114.6° to 33.4° |
| حسگر (سنسور) | 1/3" Progressive Scan CMOS |
| پیکسل | 4MP |
| حداکثر وضوح تصویر | 2688x1520 |
| کیفیت تصویر برداری | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720), 50 Hz: 25 fps (640 × 480, 640 × 360), 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720), 60 Hz: 30 fps (640 × 480, 640 × 360), Bit Rate Control CBR/VBR, H.264 Type Baseline Profile/Main Profile/High Profile, H.264+ Main Stream supports, H.265 Type Main Profile, H.265+ Main Stream supports, Main Stream, Main stream: H.265/H.264/H.264+/H.265+, Max. Resolution 2688 × 1520, Region of Interest (ROI) 1 fixed region for main stream and sub-stream, Scalable Video Coding (SVC) Yes, Sub stream: H.265/H.264/MJPEG: 640x360 up to 30 fps, Sub-Stream, Third Stream, Third stream: H.265/H.264: 1280x720 up to 30 fps, Video Bit Rate 32 Kbps to 8 Mbps, Video Compression |
| Frame Rate | 30fps |
| نوع ارتباط | RJ45 |
| دوربین تحت شبکه | بلی |
| پروتکل شبکه | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| گردش افقی و عمودی | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| کنترل شاتر | Shutter Speed 1/3 s to 1/100,000 s, Slow Shutter Yes |
| دید در شب | ICR Cut |
| صدا | Audio Bit Rate: 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/16Kbps-64Kbps(AAC)/32-192Kbps(MP2L2)/8-320Kbps(MP3), Audio compression: G.711, Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz, Environment Noise Filtering: Yes |
| درگاه Micro SD | Built-in micro SD, up to 256 GB |
| امنیت | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP |
| ویژگی ها | Built-in microphone for real-time audio security, Clear imaging against strong backlight with 120 dB true WDR technology, Efficient H.265+ compression technology, Focus on human and vehicle classification based on deep learning, High quality imaging with 8 MP resolution, Water and dust resistant (IP67) and vandal-resistant (IK10) |
| توان | 12 VDC ± 25%, reverse polarity protection, 12 VDC, 0.5 A, max. 6 W, PoE (802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W, PoE: 802.3af, Class 3, Power Consumption and Current: 12V DC, 0.5A, maximum: 6W; PoE: (802.3af, 37V to 57V), 0.2A to 0.1A, maximum: 7.5W, Power Interface Ø 5.5 mm coaxial power plug, Power Supply |
| برق بر روی کابل اترنت (PoE) | بلی |
| ابعاد | 127.3x127.3 × 95.9 mm (5.01"x5.01" × 3.78") |
| وزن | 600 گرم |
